Toroidal Core
Toroidal cores are designed for use in current and instrument transformers, offering excellent magnetic performance with low losses. We manufacture these cores using high-grade CRGO steel and are fully stress-relief annealed to give best results. All toroidal cores are custom-engineered to meet client specifications, and tested for flux density, dimensional accuracy, and magnetic performance.
Low Magnetic Leakage
Closed magnetic loop design provides high efficiency and minimal flux escape.
Compact and Lightweight
Space-saving form factor ideal for modern compact transformers and electronics.
Quiet Operation
Reduced humming and vibration during load cycles due to symmetrical construction.
High Magnetic Flux Density
Enables high power handling even in small sizes.
Technical Specifications
| Parameter | Details |
|---|---|
| Material | CRGO |
| OD Range | 50mm – 600mm |
| Thickness | 0.23mm / 0.27mm / Custom |
| Core Loss | As per material grade |
| Surface Finish | Coated / Insulated |
Applications Of Toroidal Core
